Revit "Super Users" AMA - Replay



Well... that was fun!

Last night marked the 50th episode of "BIM After Dark Live".  To mark the occasion I was joined by 6 other previous guests and Revit "super users" all with their own Revit super powers.  ;)

We took questions and discussed an array of topics for almost 2 hours!!

Some of the topics included:

- Phasing, Design Options, and more.

- What feature we wished would be in the next release of Revit

- Linear light fixtures...?

- Interior design (tagging wall materials, etc...).

- PyRevit... Lot's of PyRevit

- What versions of Revit we all started on.

- Shared Coordinates (and coordinate systems)...

... and so so much more...

This was, honestly, just a great time.  Not to mention, the chat was on fire.  Literally, the 7 of us could not even keep up with the discussions, questions, and more...

Thank you all who joined us live.  For those who didn't, continue reading to view the replay!

I've also listed all of the guests previous appearances on the show and whatever links I could scavenge together mentioned throughout the 2 hour session!

Architects, Developers, & BIM: Test-fitting with the TestFit Team (Replay)



I remember seeing a GIF of TestFit a few years back on Twitter.  It showed a 3D diagram of a simple apartment looking building and a parking lot around the outside.  The site was pulled in one direction and the building grew,  changed shape, and the parking lot reconfigured as it was stretched...

Mind blown.

Fast-forward to today, TestFit is a platform that blends architecture, building codes, crowd sourced input, real-estate developer knowledge, BIM, and generative design to completely disrupt the early stages of a project development.

On this episode of BIM After Dark Live I was joined by Clifton and Nat to not only discuss how an application like TestFit interacts with your Revit models, but also about how an understanding of what developers value and an acceptance of co-creation tools will ultimately benefit you as much as them...

The conversation was awesome, the questions were great, and Nat showed us how you can bring a TestFit building into Revit ... yes, those are Revit Walls, Floors, Roofs, etc... Automatically!

Continue reading to view the replay and see it in action....

From Revit to Unreal Engine (Replay) w/Carl Gibson



As expected, last night's episode of BIM After Dark Live was a ton of fun!

Many of you have tuned into my Twinmotion and Revit tutorials, streams, and tips... Many of you may not know that Twinmotion runs on a gaming engine called "Unreal".

On this episode of BIM After Dark Live I was joined by Carl Gibson as he ran through the process of getting your Revit models into the Unreal Engine environment for renderings, animations, and VR!

Some of the topics Carl touched on are:

-Summary of tools needed (Revit, Unreal Engine, Datasmith Exporters)

-Prepping a model for Datasmith

-Importing into UE

-DataPrep graph for model optimization, material replacement, etc.

-Setting up a project for VR.

If you have been wanting to learn the process of getting your model's into Unreal or are curious as to what Unreal can do for you, be sure to check out the replay below...

Interactive 3D Revit Models in Power BI (w/Nate Miller) - Replay w/Links



On yesterday's episode of BIM After Dark Live I was joined by Nate Miller to talk about Revit, Power BI, and an application he built that gives you the ability to interact with 3D models IN a Power BI dashboard... Nate is the founder of Proving Ground, and has a long history of creating useful applications for architects, engineers, and contractors including LunchBox, Rhynamo, & Slingshot. Nate will be joining us to talk about some of his new projects that deal with how Power BI can interact with 3D modeling programs (like Revit & Rhino). Tracer, his suite of applications that let you export Revit data, import it into Power BI, and generate an interactive 3D model (in Power BI) is sure to be a game changer for data analytics, visualization, and more...

We had a great conversation, Nate showed some awesome stuff, and there were excellent questions from the audience...

Continue reading to view the replay and the links mentioned (and to try out Nate's dashboards!)...

Dynamic Data Images with Revit and Power BI (Synoptic Panel) (Replay w/Links)



On this episode of BIM After Dark Live I demonstrated the process of connecting Power BI visual data to 3D model images created in Revit... Essentially, this is the next best thing to actually having your models IN Power BI... We'll get to that next week... ;) If you are wondering what this could look like, check out this link and click the images of the building on the top right... See how you can interact with the image and the data dynamically?! That is what I will show you in the episode... Topics Covered: - Exporting Images - Exporting Revit Data for Power BI

- Making a "smart" layered SVG file (Adobe Illustrator) - Using "Synoptic Panel" in Power BI -Importing Revit Data into Power BI - Tying it all together...

Continue reading to view the replay and links mentioned...

DynaMaps and Revit - Adding Context to Your Models (w/Mostafa & Paul Aubin)



On last night's episode of BIM After Dark Live we welcomed Mostafa El Ayoubi.  Mostafa is an architect and civil engineer.  He is the creator of Dynamo packages like DynaMaps and Data-Shapes.

This episode introduced the genesis of the DynamMaps package and it’s foundations as well as some workflows showing how to get site geometry inside Dynamo and push it to Revit will then be live demoed.

Also, this was another "crossover" with Paul Aubin and the ChiNamo users group!

Topics Included:

- Introduction to DynaMaps

- Installing the Package

- Step by Step demonstration of how to bring in buildings, topography, roads, and trees from open source data to your Revit models.

Continue reading to view the replay and learn how to install and use DynaMaps today!

Parametric Dining Room Light Fixture Family in Revit - Start to Finish



I built a parametric family in Revit on yesterday's episode of BIM After Dark Live.

But, not just any old Revit family.  A dining room light fixture.

Why a light fixture family?

Well, I've noticed over the years that light fixtures are probably some of the most wanted families.  Probably because there are literally millions of fixture with all sorts of little details within them.

Another reason I wanted to walk you through the creation of this fixture live is that is contains a whole bunch of great family creation tips and tricks along the way.

There were some great questions and I shared a lot of "process" references (like sketches, and diagrams) that are worth checking out...

Topics Covered:
- Laying out a Parametric Object
- Using Nested Families (when, why, and how).
- Using multiple light sources in one family.
- Carrying parameters (like materials) through nested Families
- When to use sweeps over extrusions
- Tips for making "rods"...

And so much more.

If you missed it, be sure to continue reading to see the replay and view all of the reference materials...

AMA Replay (Plus, a 30% Off Discount!)



To wrap up 2020 with a bang, I thought it would be fun to host another "Ask Me Anything (AMA)" style episode of BIM After Dark Live.  The last time I did an AMA style episode was almost 20 episodes ago.

That day, I hosted a double header and couldn't even keep up with all the questions I got!  (Check out the replays here.)

Yesterday, there were so many questions is was hard to keep up!  Thank you all for joining, asking questions, and making this live show thing... well, a thing!

Topics the we Covered:

- Building a wall under a ramp (and other ramp options).

- Creating Door Window and Curtain Wall Elevations (touched on it).

- Revit Backup File Management

- Creating a Concrete Mass in Revit

- Using the overhead line trick ... sort of ...

- 3D Details and When to Model versus draft (hint, MODEL MODEL!).

- My middle name...

Continue reading to view the episode...

The Dynamo and Grasshopper for Revit Reference Manual (Replay)



On this episode of BIM After Dark Live I was joined by a very special guest, Marcello Sgambelluri. Marcello was on the show a few months ago and mentioned a book he was writing... Well, that book is now available! "The Dynamo and Grasshopper for Revit Cheat Sheet/Reference Manual" is 272 pages of pure awesomeness. Marcello includes hundreds of working Dynamo scripts and their working counterpart in Grasshopper (for Revit). We talked about the book and how knowing BOTH of these tools expands the functionality of Revit for you.

We also had a little fun when I did an example of a practical use of one of Marcello's scripts in Dynamo followed by Marcello demonstrating how to do the exact same thing in Grasshopper/Rhino... Super cool!

Continue reading to view the replay and download the sample files from our demonstration (including the Rhino, Grasshopper, Revit, and Dynamo files...)

Calculating Occupancy in Revit, Automatically



On the latest episode of BIM After Dark Live I was joined by Dana De Filippi to talk about automatically calculating (and tagging) occupancy loads in Revit.  Dana is a co-host on the BIM Thoughts Podcast and a BIM technologist within the field of architecture and kicks all kinds of Dynamo butt.

Dana shared the workflow she developed that will automatically (and accurately) calculate your occupancy loads and place them into tags for you!  Something I know you all just love doing manually ... ;)

Topics Covered:

- Creating and using Area Schemes in Revit

- Constructing key values and using conditional formatting in Revit schedules.

- Use Dynamo to collect Revit and Excel Data

- Discover how to integrate user selection of different code requirements.

This is a DO NOT MISS for all of my fellow Architects out there (and FP engineers, too!)...

Continue reading to view the episode and download the sample files Dana was so gracious to share!

Revit + Twinmotion 2020: Rendering a Night Scene (Tips and Tricks)



On this special Tuesday episode of BIM After Dark Live I gave an update on my own house project and jumped back into some Revit & Twinmotion 2020 content.

We talked about rendering night scenes in Twinmotion 2020 with Revit.

This episode was inspired by a student's question following our Twinmotion class.  She asked about making a "moody" nights scene.  Then, it dawned on me, I had yet to make a NIGHT SCENE in Twinmotion.

So, I dug in, spent some time, and figured out some of the tips and tricks to creating sexy, moody, and super-fun images!

Continue reading to view the replay an all of the links mentioned (including my FREE Revit to Twinmotion course...)

Flipped Interview w/ BIM Thoughts (Talking AU2020, Fishing, & More!) + Announcements!



On last night's episode of BIM After Dark Live, I welcomed Dana, Bill, and Carl from the BIM Thoughts podcast.  It was nice to have a drink, sit back, and chit chat about myself, AU2020, 3D printing, fishing, and more...

Also, a couple important event notes for next week (before you check out for the holidays!):

Continue reading to view the discussion and links mentioned...

Tips for Deploying Dynamo Scripts w/John P (+ Datasets)



On yesterday's episode of BIM After Dark Live I was joined by the one and only SixySecondsRevit (aka John P). John is a Design Technologist at Parallax Team and is also the creator of one of my favorite Dynamo custom packages (Rhythm). John will be talking about his approaches to handing off and deploying Dynamo (for Revit) scripts. This is huge! Once you've created the greatest script ever, understanding how to share it and let other users actually use it is the next big step... Some things John and I discussed... - Drop down considerations (for Revit versions) - Grouping ideas

- Dynamo Templates!!!?!? - Showing View Extensions to Help - and more...

Continue reading to view the episode and download the datasets...!

Advanced Revit Railings (w/Revit Pure) + Big News!



On last night's episode of BIM After Dark Live I was joined by Nick from Revit Pure and we got REALLY deep into railings...

Maybe, too deep?

No way!

Nick was forced to learn every little property within the railing tool when he was tasked with modeling an old ancestral stair (seen in the image above being slid down by The Revit Kid, haha).  Nick used this opportunity to document what he was learning and share it with us all!!

Topics Covered:

- Difference between top rail, mid rail, and hand rail...

- Stacking Balusters

- Building Custom Terminations

- Dealing with extensions.

- Mitering and Fileting rails....

... and so much more ...

Build Your FIRST Parametric Revit Family, Today! (Replay)



Just in case you missed it... Yesterday was the 30th episode of BIM After Dark Live!!

Pretty cool!

During the episode I taught the fundamentals of creating parametric content (families) in Revit.  This was not your ordinary "here is how you build a family" lesson, though.  I really stressed the concepts behind how a parametric family, reference planes, and constraints work.

Even if you think you KNOW how families work... This episode may be worth a watch!

Of course, given that it is a live show, we also had some great questions from live viewers!

Continue reading for the episode 30 replay and links mentioned....

3 Steps to Beginning Your Dynamo Journey, Today (+ Special Offer)



Well, that was fun!  It has been a while since I talked in depth about Dynamo.

On the latest episode of BIM After Dark Live I walked through the 3 steps it takes to start learning Dynamo (click here to see all of my related posts about Dynamo).  These steps help you get into the right frame of mind and give you a starting point when entering the Dynamo world...

There were also some great questions from the audience and even a cameo from some of the Dynamo superstars (like our good friend, John...).

Laser Scanning and Revit - What you NEED to Know (Replay)



On last nights episode of BIM After Dark Live, I was joined by Matt Stachoni to talk about laser scanning.  Long story short... Matt went DEEP into the details of laser scanning basics.  Additionally, the live audience had some great questions along the way.

Matt talked about everything from the different types of laser scanners, to what registering a scan is REALLY like, to his preferred process to checking a scan against a Revit model for QA/QC and as-built verification...

I, for one, had a new appreciation for when I ask a surveyor to scan, register, and model an existing structure for me.  Having a better understanding of the registration process and what is involved is going to help me down the road whether I scan myself or procure it from others.

Matt dropped a ton of laser scanning knowledge and still clearly had more to share.  Hopefully he will join us again soon!

Continue reading to view the replay and links mentioned...

Good Looking, Fully Organic, All Natural, "NURBS" in Revit (w/Tim Waldock)



On last night's episode of BIM After Dark Live I am excited to have Tim Waldock (of the Revit Cat blog) on the show.  I've been following Tim's blog for many years and I have always loved the way he dives into the nitty gritty details of Revit features and functions.

Tim will be demonstrating some of the awesome techniques he has developed for creating super smooth, good looking, organic forms in Revit.

When I say organic, I literally mean he showed us how to model some vegetables (or a fruit?)...

Revit isn't known for being able to display super smooth "NURBS" type of shapes but Tim has some tips and tricks to help you out.  From random blob shapes to beautiful modern furniture, I guarantee you'll find a use for what Tim has to show.

Continue reading to view the episode and see any related links mentioned....

Revit & Enscape 2.8: Design, Present, Collaborate (w/Dan Stine)



Dan Stine returned to BIM After Dark Live last night to talk about some of the new features in Enscape 2.8 (and what's to come in Enscape 2.9)...  Similar to our previous episode with Dan he didn't just run through the features, he also demonstrated some useful tips and tricks along the way!

Personally, I am most excited about all of the new healthcare content in Enscape 2.8, but even more excited about the FBX/OBJ import options in 2.9 to come!!!

Topics Covered:

Enscape 2.8

BIM 360 freeze fixed
Collaborative annotation
"Puddle Tip/Trick"
Animated vegetation
New assets
Carpet material
BIM Mode

Version 2.9 beta

Video textures
Custom asset library (and editor!!!)
Offline asset library

Continue reading to view the episode and the links mentioned...

Let's Talk Topography: Creating Site Models in Revit



Wow, I can't believe we are already at Episode 25 of BIM After Dark. Live!  It's pretty wild to see what a simple virtual happy hour has turned into over the last 6 months.  Thank you all for tuning in (live or after the show) and staying engaged!

On this episode I dive into the world of modeling topography and site components in Revit.  I go over all kinds of need tricks, tips, and hacks that will help you create site models with a little more speed and a little less frustration...

We talked about:

- The Auto-Clicker Method
- The rarely used "Site Settings" Dialogue
- My secret way of making striping, retaining walls, earth retention, and underground utilities!

Continue reading to view the episode and the links mentioned...
